Bluetooth Low Energy | RSL15

蓝牙5.2安全无线MCU

产品

添加至我的收藏

数据表
CAD Model

CAD模型

概览

RSL15是一款基于Arm® Cortex®−M33处理器的超低功耗安全低功耗蓝牙5.2无线MCU，专为工业和医疗应用中的智能互联设备而设计。RSL15具有内置电源管理、宽广的电源电压范围、灵活的GPIO和时钟方案以及广泛的外设集，为高性能和超低功耗应用提供了最大程度的设计灵活性。 RSL15包含80kB RAM，并有284kB或512kB两种闪存选择。

  • 工业自动化和传感
  • 医疗互联传感器
  • 可穿戴设备
  • 资产追踪
  • 电子标签和门禁控制
  • 电子标牌
  • 数据记录器
  • 智能电器
  • 能量收集开关

物质成分

产品更改通知
软件开发套件（SDK）配置全面，易于操作，包含驱动程序、程序库、示例代码、开发工具和移动应用程序（适用于iOS®和Android™的RSL Central及适用于iOS和Android的RSL FOTA）开发环境包含安森美IDE、Keil μVision® 和IAR内置Work Bench®。

下载下方的SDK文件开始使用RSL 15:

  • RSL15 Documentation Package
  • onsemi IDE Installer
  • RSL15 Firmware Package

下载和解压文件RSL15 Documentation Package，打开'RSL15_documentation.htm' 找到RSL15 Getting Started Guide完成安装并开始使用RSL15。



DownloadsSoftware ProductDescriptionVersionDate Updated
ZIP

RSL15 Documentation Package

Start here.  Getting Started Guide, Developer's Guide and detailed firmware and hardware documentation

1.9

Mar 2024

ZIP

onsemi IDE Installer

Eclipse-based onsemi IDE

4.4

June 2023

ZIP

RSL15 Firmware Package

RSL15 CMSIS-Pack containing drivers, libraries, and sample code and SDK release notes

1.9

Mar 2024

ZIP

RSLSec

PC application to manage device security features, lifecycle states and the manufacturing provisioning process

1.5

Mar 2024

ZIP

BLE Explorer

PC application that acts as a Bluetooth central to your peripheral device (requires RSL10-USB001GEVK)

2.0

May 2024

ZIP

RF Tools

PC application to help test, tune and validate Bluetooth Low Energy RF PHY performance

1.1

Aug 2022

Visit the Community Forums to learn more and join the conversation.

产品列表

如需购买产品或样品，请先登录您的安森美账号。

搜寻

Close Search

产品:

3

分享

排序方式

产品系列:

┗

可订购器件:

3

产品

状态

CAD Models

Compliance

Package Type

Case Outline

MSL Type

MSL Temp (°C)

Container Type

Container Qty.

ON Target

Security

Bluetooth Low Energy Feature

Reference Price

NCH-RSL15-284-101Q40-ACG

Contact Sales

Active

CAD Model

Pb

A

H

P

QFN-40

485CR

3

260

REEL

1500

F

arm CryptoCell

Long Range

$3.45

More Details

NCH-RSL15-512-101Q40-ACG

Contact Sales

Active

CAD Model

Pb

A

H

P

QFN-40

485CR

3

260

REEL

1500

Y

arm CryptoCell

Long Range

$3.7375

More Details

NCH-RSL15-512-101WC40-ABG

Contact Sales

Active

CAD Model

Pb

A

H

P

WLCSP40 2.301x2.499x0.369

567HU

3

260

REEL

1500

F

arm CryptoCell

Long Range

$3.3333

More Details

Show More

1-25 of 25

Products per page

Jump to :

1
