PC/Laptop form factors are getting smaller, thinner, and lighter with the adaptation of the USB-C (Type-C) connectors. ON Semiconductor offers multiport solutions compatible with the USB-C Port Controller Protocol and Power Delivery 3.0.
Function | Device | Description | Download Data Sheet |
---|---|---|---|
Voltage Regulation | NCP81231 | Buck Controller, USB Power Delivery and Type-C Applications | ![]() |
Protection | ESD8704 | High Speed Data Line Protection, Unidirectional (3.3 V – USB 3.x) | ![]() |
ESDL2011 | High Speed Data Line Protection, Bidirectional (1 V – Thunderbolt 3.0), 0.2 pF | ![]() |
|
ESDM3551 | ESD Protection Diode, CC and SBU Protection (5.5 V – USB 3.x), 21 pF | ![]() |
|
NSPM2052 | ESD and Surge Protection Device, Vbat and Vbus Applications, 5 V | ![]() |
|
NIS5135 | Electronic Fuse, 5 V | ![]() |
|
NCS210R | Current Sense Amplifier, Bidirectional Zero-Drift, 1% Max. Gain Error, 60 µV Offset | ![]() |
|
NCS211R | Current Sense Amplifier, Bidirectional Zero-Drift, 1% Max. Gain Error, 60 µV Offset | ![]() |
|
NCS213R | Current Sense Amplifier, Bidirectional Zero-Drift, 1% Max. Gain Error, 100 µV Offset | ![]() |
|
NCS214R | Current Sense Amplifier, Bidirectional Zero-Drift, 1% Max. Gain Error, 60 µV Offset | ![]() |
|
FUSB252UMX | High Speed Digital (HSD) Port Protection Switch with Type-C CC | ![]() |
|
FSUSB242UCX | USB Type-C Port Protection Switch | ![]() |
Function | Device | Description | Download Data Sheet |
---|---|---|---|
Power Regulation | NCP1342 | Quasi-Resonant Flyback Controller with Valley Lock-Out Switching | ![]() |
NCP4306 | Secondary Side Synchronous Rectification Driver for High Efficiency SMPS Topologies | ![]() |
|
FAN65004B | Synchronous PWM Buck Regulator, High Performance, Voltage Mode, 65 V, 6A | ![]() |
|
FAN65005A | Synchronous PWM Buck Regulator, High Performance, Voltage Mode, 65 V, 8A | ![]() |
|
FAN65008B | Synchronous PWM Buck Regulator, High Performance, Voltage Mode, 65 V, 10 A | ![]() |
|
Power Mux | FPF2595UCX | Load Switch, Over-Voltage, Over-Current Protection with Adjustable Current-Limit Control, IntelliMAX™ 28 V | ![]() |
FPF2895CUCX | Current Limit Load Switch with OVP and TRCB, 28 V, 5 A | ![]() |
Function | Device | Description | Download Data Sheet |
---|---|---|---|
Data Redriver | NB7NPQ7021M | USB 3.1 Dual Channel Linear Redriver, 3.3 V | ![]() |
NB7VPQ904M | 1.8V USB Type-C™ DisplayPort™ ALT Mode 10Gbps Linear Redriver |
Request this document |
|
NB7NPQ1102M | 3.3 V USB 3.1 Gen-2 10 Gbps Dual Channel / Single Port Linear Redriver | ![]() |
|
NB7NPQ1104M | 3.3 V USB 3.1 Gen-2 10 Gbps Quad Channel / Dual Port Linear Redriver | ![]() |
|
SuperSpeed MUX | FUSB340TMX | USB 3.1 SuperSpeed Switch, 10 Gbps | ![]() |
Alt Mode MUX | FSA4476UCX | Analog Audio Switch with Protection Function, USB Type-C | ![]() |
FSA4480UCX | USB Type-C Analog Audio Switch with Protection | ![]() |
Function | Device | Description | Download Data Sheet |
---|---|---|---|
Port Control | FUSB302BMPX | Programmable USB Type-C Controller with PD (Default SNK) | ![]() |
FUSB303TMX | Autonomous USB Type-C Port Controller with I2C and GPIO Control | ![]() |
|
FUSB307BMPX | USB Type-C Port Controller with USB-PD (Default SNK) | ![]() |
|
NCP1095 | Power Over Ethernet – Powered Device Interface Controller, IEEE 802.3bt | ![]() |
|
NCP1096 | Power Over Ethernet – Powered Device Interface Controller with integrated hot swap FET, IEEE 802.3bt | ![]() |
Video ID | Video Title |
---|---|
WVD17184/D | New Standard - What is USB Type-C? |
WVD17185/D | How to Implement Innovative USB Type-C Solution into Your System |
WVD17181/D | USB Type-C port controller demo |
WVD17249/D | High Density USB-PD Adapter Solution - Active Clamp Flyback PWM Controller Demonstration |
WVD17335/D | 11 Myths About USB Type-C Part 1 |
WVD17336/D | 11 Myths About USB Type-C Part 2 |
Blog Post | Title |
---|---|
September 25, 2019 | Optimizing for USB Power Delivery Design – Multi-mode PWM Controller |
December 6, 2018 | USB-C PD Fast Role Swap - The Consumer Experience Uninterrupted |
November 14, 2018 | USB-C and Automotive Electronics – Where Power Meets the Road |
September 27, 2018 | Ensuring Analog Audio Output with USB-C |
August 8, 2018 | Power Banks with USB-PD to Relieve Battery Anxiety |
July 23, 2018 | Becoming More Bond-like by Quickly Implementing USB-C Solutions |
May 29, 2018 | Evolving USB-C and PD Standards - A Double Edged Sword for Design Engineers |
April 25, 2018 | USB-Power Delivery Design Using 4 Switch Buck-Boost Converters |
April 5, 2018 | New Turnkey Solution for USB-C |
March 19, 2018 | How to Easily and Quickly Upgrade Your USB® Design with USB-C Solutions |
January 31, 2018 | USB Type-C – It’s All About Flexibility, Small Size and Low Power |
