Power over Ethernet (PoE) is a collective of standards that describe how to pass power together with the data over twisted pair Ethernet cabling. This disruptive technology allows power sourcing equipment (PSE) to transfer power to the application safely, called a powered device (PD).

IEEE standard certifications guarantee interoperability between various equipment. We supply Powered Device interface and power conversion ICs, adhering to the IEEE 802.3af, IEEE 802.3at, and IEEE 802.3bt standards.

A handshaking process between the Power Sourcing Equipment (PSE) and Powered Device (PD) manages power transfer in PoE systems. The PSE detects if the PD is PoE capable and determines the power requirements based on defined device types and classes during this process.

Interactive Block Diagram

2 添加器件
Select checkbox next to product and then Add to Worksheet button.
3 下载工作表
工作表预览:
应用座 按产品类型 产品

Evaluation/Development Kits

PoE-PD Interface Controller Evaluation Board, IEEE 802.3bt

Enables evaluation of NCP1096 controller and includes RJ-45 connectors, power transformer, active bridge (Greend Bridge2) and other fixtures to help the end user with testing.

Technical Documents

Quad MOSFET Delivers Dramatic PoE Efficiency Over Diode Bridge Alternatives

There are several methods for configuring a PoE network. The preferred approach depends on a variety of factors.

PD Rectifier Bridge Circuits

Power over Ethernet (PoE) is a technology which allows power sourcing equipment (PSE) to safely transfer power toa powered device (PD) through an Ethernet cable.
