MOSFETs | NVMFS6H852N

功率 MOSFET，80V，43A，14.2mΩ，单 N 沟道，SO8-FL

相似产品推荐

产品

添加至我的收藏

数据表
CAD Model

CAD模型

概览

适用于紧凑和高效设计的汽车用功率 MOSFET，采用 5x6mm 扁平引线封装，且具有较高的热性能。可用于增强光学检测的可润湿侧翼选项。通过 AEC-Q101 认证的 MOSFET，符合生产件批准程序 (PPAP)，适用于汽车应用。

  • Switching power supplies
  • Power switches (High Side Driver, Low Side Driver, H-Bridges etc.)
  • 48V systems
  • Motor Control
  • DC/DC converter
  • Load Switch
  • Small Footprint (5x6 mm)
  • Low RDS(on)
  • Low QG and Capacitance
  • NVMFS6H852NWF − Wettable Flank Option
  • AEC−Q101 Qualified and PPAP Capable
  • RoHS Compliant

物质成分

产品更改通知

产品列表

如需购买产品或样品，请先登录您的安森美账号。

搜寻

Close Search

产品:

2

分享

排序方式

Product Groups:

┗

Orderable Parts:

2

产品

状态

CAD Models

Compliance

Package Type

Case Outline

MSL Type

MSL Temp (°C)

Container Type

Container Qty.

ON Target

V(BR)DSS Min (V)

RDS(on) Max @ VGS = 10 V (mΩ)

Channel Polarity

Configuration

VGS Max (V)

VGS(th) Max (V)

ID Max (A)

PD Max (W)

RDS(on) Max @ VGS = 2.5 V (mΩ)

RDS(on) Max @ VGS = 4.5 V (mΩ)

Qg Typ @ VGS = 4.5 V (nC)

Qg Typ @ VGS = 10 V (nC)

Ciss Typ (pF)

Reference Price

NVMFS6H852NT1G

Loading...

Active

CAD Model

Pb

A

H

P

SO-8FL / DFN-5

488AA

1

260

REEL

1500

Y

80

14.2

N-Channel

Single

±20

4

43

54

~NA~

~NA~

~NA~

13

760

$0.4057

More Details

NVMFS6H852NWFT1G

Loading...

Active

CAD Model

Pb

A

H

P

DFNW5 5x6 (FULL-CUT SO8FL WF)

507BA

1

260

REEL

1500

Y

80

14.2

N-Channel

Single

±20

4

43

54

~NA~

~NA~

~NA~

13

760

$0.4057

More Details

Show More

1-25 of 25
