USB与无线充电
Intelligent Solutions for Modern USB-C Battery Chargers
Design compact, high‑efficiency USB‑C battery chargers with scalable power architectures, USB‑C PD compliance, and proven reference designs—accelerating time to market across end devices.
概览
The USB & Wireless Charger is a versatile and efficient charging solution designed to power multiple devices simultaneously. Ideal for both home and office use, this charger supports a wide range of gadgets, including smartphones, tablets, and other USB-enabled devices, offering a seamless and convenient charging experience.
Power Switch Selection in Computing USB-C Power Path
Explore power switch selection and design in the USB‑C power path, addressing USB Power Delivery (PD) control, protection mechanisms, efficiency, and system reliability.
White Paper View Products
SiC Cascode JFETs: Easing the Transition from Si to SiC
Our high-performance SiC cascode JFETs deliver best-in-class switching speed, lower switching losses and higher efficiency for power supply units (PSUs).
View Products White Paper
Previous
Next
产品
USB Type-C
FUSB302B
Programmable USB Type-C Controller with PD (Default SNK)
USB Type-C
FUSB302T
Programmable USB Type-C Controller with PD (Default SRC)
USB Type-C
FUSB303BTMX
Autonomous USB Type-C Port Controller with I2C and GPIO Control
USB Type-C
FUSB15201
Integrated Dual Port USB Type-C & PD Source Controller
Analog Switches
FUSB340
USB 3.1 SuperSpeed Data Switch, 10 Gbps
Low/Medium Voltage MOSFETs
Portfolio of comprehensive range of Low-medium voltage power Mosfets that delivers superior performance and reliability for switching applications. Our cutting-edge PowerTrench® T10 technology delivers industry leading RDS, higher power density, reduced switching losses and better thermal performance.
Silicon Carbide (SiC) Cascode JFETs
Our high-performance SiC cascode JFETs deliver best-in-class switching speed, lower switching losses, and higher efficiency. They provide high switching frequency and deliver ultra-low on-resistance (RDS (on)) starting at just 5mohm, utilizing less than half the die size of any other technology. Available in both standard thru-hole (including Kelvin) and surface mount packages, they offer excellent cost-effectiveness.
These devices utilize a unique cascode configuration, integrating a high-performance SiC fast JFET with a cascode-optimized Si-MOSFET. This innovative approach enables standard gate drive (0-12V) for SiC devices. Given their smaller die size and compatibility with existing driver solutions, the SiC cascode JFETs offer optimized system performance and cost structure.
Power Factor Controllers
NCP1680
Totem-Pole Critical Conduction Mode (CrM) Power Factor Correction Controller
Power Factor Controllers
NCP1681
Totem-Pole Continuous Conduction Mode (CCM) / Multi-mode (CrM-CCM) Power Factor Correction Controller
Offline Controllers
NCP1345
Highly integrated quasi-resonant flyback controller for off-line USB-PD and USB Type-C power converters.
Secondary Side Controllers
NCP4306
Secondary Side Synchronous Rectification Driver for High Efficiency SMPS Topologies
Converters
FAN65004B
Synchronous PWM Buck Regulator, High Performance, Voltage Mode, 65 V, 6 A
Documents
Reference Designs
240 W USB PD3.1 EPR - CrM Totempole PFC and 2 Switch Flyback Solution
Reference Designs
240 W UHD Power Supply - CrM Totempole PFC and Current Mode LLC HB Solution
White Papers
Considerations for Power Switch Selection in Computing USB‐C Power Path
Reference Designs
240 W USB PD3.1 Solution
Application Notes
Loop Compensation of Voltage‐Mode Buck Converters – Example for FAN65004B
White Papers
采用基于 GaN 的 300 W 图腾柱 PFC 和 LLC 电源应对超高密度设计挑战
White Papers
Advantages of Integrated GaN Devices in AC-DC Solutions
White Papers
SiC Cascode JFET：轻松实现从硅向碳化硅的过渡
Reference Designs
60 W USB-PD and Quick Charge 3.0 Buck-Boost Reference Design Documentation Package
评估板/套件
Evaluation Board
NCP1343PD100WGEVB
NCP1343 100 W USB PD Evaluation Board
Evaluation Board
NCP1345PD65WGEVB
Evaluation Board
FUSB15201DUAL60WGEVB
Evaluation Board
FUSB302TGEVB
Evaluation Board
NCP1342PD65WGEVB
USB-C Battery Charger
USB Type-C & PD Port Controllers
A product portfolio of USB Type-C devices that include a variety of low power USB Type-C controllers, including those with Power Delivery (PD) protocol.
USB-C Battery Charger
MOSFET Technology
Achieve your design goals with onsemi's superior LVMV MOSFET technologies, delivering exceptional quality, robustness, and scalability to meet your mission-critical system needs.
精选文章
为您精选的新闻和博文，挖掘创新灵感，洞见行业趋势。
